The Gator Audio Road Rack Case is the elite gold standard for touring live sound engineers, production rental houses, and mobile arena rigs. Because heavy-duty server frames, massive power amplifiers, and deep outboard processors generate immense transit stress. This professional flight enclosure shields your investments during rough truck loading.
Tour-Ready Engineering of the Gator Audio Road Rack Case:
Choosing the right structural housing requires inspecting the raw materials. Because it is crafted from 9mm commercial-grade plywood and a protective external PVC skin, this resilient frame absorbs extreme lateral shocks. Consequently, you maintain flawless equipment operation while preventing costly rack ear bending. Furthermore, a tongue-and-groove extruded aluminum valance wraps around the front and rear removable lids to block out harmful venue dust and road moisture. For secure logistics, the heavy lids fit tightly against the main frame. Therefore, you protect sensitive front knobs and rear wire connections during chaotic stage load-outs.
Advanced Mechanical Rigging Components:
• Heavy-Duty Rolling Transit: Outfitted with four industrial-grade 4-inch wheels, allowing a single stagehand to position heavy racks.
• Superior Fastening Closures: Equipped with vibrant red recessed MOL twist butterfly latches that stay completely flush with the exterior walls.
• Premium Shock Shielding: Built with zinc-plated commercial-grade hardware and reinforced stackable steel ball corners to distribute drop weight.
• Dual Grid Framing: Additionally, the dual front and rear 3.2mm thick rack rails allow multi-sided layout configurations.
Exact Rigging Specs and Depth Clearance:
This mobile audio workstation offers standard 19-inch wide internal mount spacing along with a 24-inch overall rackable interior depth. Specifically, the thick heavy-duty rails securely hold standard mounting screws without stripping out during cross-country transit.
Before committing to your configuration, double-check your amplifier chassis lengths to guarantee a flush fitment with the rear lids closed. Do not risk system downtime mid-tour due to low-grade protective enclosures. In conclusion, buy your Gator Audio Road Rack Case today from Midwest Case Company to guarantee maximum gear safety on the road.
Case Specifications:
- Interior Dimensions (L x W x H): 19″ x 28″
- Exterior Dimensions (L x W x H): 30″ x 21.5″ x 36″
- Part Number: G-TOUR16UCA-24D
- UPC Code: 716408521015
Key Features:
- 16U rack space — roomy enough to mount mixers, effects units, power amps, processors and other 19″-rack gear.
- 24″ deep rack rails — provides deeper mounting capacity to accommodate bulkier gear.
- ATA-style wood flight case construction — rugged 9 mm plywood with a laminated exterior that stands up to repeated travel and road use.
- Heavy-duty hardware — commercial-grade plated corners and red recessed twist latches for secure closure and stackability.
- Built-in casters — makes it easier to move fully loaded gear without having to lift the case.
- Front & rear 3.2 mm thick rack rails — sturdy support suited for professional equipment.
- Spring-loaded handles — for easier maneuvering and transport.
- Lifetime warranty on manufacturing defects — Gator backs the product against material/workmanship issues.
What It’s Best For: This ATA-rated road case is ideal for touring, rental/staging, Streaming interrupted.
